Product info
Technical Data:
TCT sawblade ų: 315 mm / 48 Teeth
Sawblade speed: 4000 rpm
Cutting speed: 66 m/sec for fast cuts without tearing out
Table size: 805 x 680 mm
Table height: 850 mm
Sawblade height adjustment: 0 to 110 mm
Sawblade swinging range: 0° to 45°
Suction connection piece: ų 100 mm
Dimensions: L 1350 x W 760 x H 1110 mm
Weight approx. 215,0 kg
Standard equipment:
Cross-cutting gauge, swinging range 2 x 60°
Table length extension, L 440 x W 670 mm
Ripping fence with magnifying glass, fine-adjustment, and reversible fence rail, 800 mm long
Push stick, push handle, assembly tools
Suction hose-ų 50 mm, sawblade cover
Phase inverter (400V)
Cutting height at 90°: max. 110 mm, at 45°: max. 77 mm
Cutting width with ripping fence: 390 mm
Cutting width with table width extension: 1100 mm
Cutting depth in front of sawblade with cross-cutting gauge: 260 mm
Cutting depth in front of sawblade with sliding table carriage 1400: 800 mm; with sliding table carriage 2000: 1400 mm
Certificates CE, GS, tested for wood dust
