DDrilling performance
Drilling performance steel (S235JR)15,9 mm
Continuous drilling performance steel (S235JR)14 mm
Drilling table
Workspace length200 mm
Workspace width200 mm
T-groove typediagonal
T-groove size14 mm
Max. distance spindle - drilling table319 mm
Electric Data
Supply voltage230 V
Phase(s)1 Ph
Current typeAC
Mains frequency50 Hz
Machine base
Max. distance spindle - machine base518 mm
Work area length145 mm
Work area width143 mm
Motor(s)
Spindle motor drive output0.45 kW
Speed range
Speed range600 – 2400 min¯¹
Number of gears5 Stages
Spindle
Quill stroke60 mm
Spindle chuckMT 2
Reach 127 mm
