Tilaustuote. Kysy toimitusaikaa
Power Input: 1600 Watts
Power Output: 930 Watt
Blade Speed: 3500 - 4600
Blade Diameter: 216x30 mm
Bevel Capacity: 48/-2 °
Mitre Capacity [right/left]: 60/50 °
Cutting Capacity at 90°/45° (W x H): 300x50 mm
Cutting Capacity at 90°/90° (W x H): 300x70 mm
Cutting Capacity at 90°/90° (W x H): 300x70 mm
Cutting Capacity at 45°/90° (W x H): 212x70 mm
Cutting Capacity at 45°/90° (W x H): 212x70 mm
Cutting Capacity at 90°/45° (W x H): 300x50 mm
Max. Cutting Capacity at 45°/45°: 208x50 mm
Max. Depth of Cut: 85 mm
Weight: 19.5 kg
New mitre angle adjustment system provides accurate and consistent setting of mitre angles between 0 and 60° right and 0 and 50° left
The innovative grooving stop allows adjustment of the cutting depth for grooving and rebating applications
The large dual sliding fence mechanism gives maximum support in large material cuts at any angle or combination of angles
Horizontal rails create additional capacity for larger materials
The aluminium base construction provides stability to the saw while still retaining its portability
60° right mitre angle provides enough capacity for the most difficult applications
Mitre and bevel angle detents allow for quick and easy set up of the saw
Spindle lock for easy blade replacement
Scope of delivery:
TCT tooth saw blade, blade spanner, material clamp
