Drilling performance
Drilling performance steel (S235JR)18 mm
Continuous drilling performance steel (S235JR)16 mm
Drilling table
Workspace length230 mm
Workspace width245 mm
T-groove typediagonal
T-groove size12 mm
Max. distance spindle - drilling table370 mm
Electric Data
Supply voltage230 V
Phase(s)1 Ph
Current typeAC
Mains frequency50 Hz
Machine base
Max. distance spindle - machine base485 mm
Work area length200 mm
Work area width240 mm
Motor(s)
Spindle motor drive output1.5 kW
Speed range
Speed range100 – 6000 min¯¹
Spindle
Quill stroke65 mm
Spindle chuckMT 2
Reach 132 mm
